Neuenhauser 3F star screen reliable and versatile.
The Neuenhauser 3F Star Screen is a powerful and flexible solution for the efficient separation of a wide range of materials. Thanks to the extensive selection of available stars and quick-change screen decks, the machine can be easily adapted to different applications. The 15° ascending screen deck and long discharge belts with hot-dip galvanized frames (optionally available in extra-wide versions) ensure optimal throughput and performance.
Operation is simple, and the machine is available in both wheel- and track-mounted designs. A walkway along the screen deck, optionally in double width, and an extendable maintenance platform provide a safe and accessible working environment. Hydraulic support legs guarantee high stability, while the engine management system with ‘ECO’ mode optimizes fuel consumption and reduces operational costs.
Additional options such as a dosing auger (height-adjustable, also remotely), tipping grid, or vibrating grid make the 3F Star Screen even more versatile. By screening fine material before coarse material, the machine operates energy-efficiently and environmentally friendly.
The 3F Star Screen is ideal for soil remediation, biomass processing, and recycling a variety of waste materials, including household, garden, and commercial waste. Its efficient tracked chassis provides excellent stability and mobility, even in difficult terrain, ensuring optimal screening performance under challenging conditions.
| Feature | Specification | |
| Semi-trailer/fifth-wheel trailer for 80 km/h as per StVZO, with ABS | Seld-driving tracked chassis frame; two travel speeds | |
| Total weight | Approx. 19.000 kg | Approx. 24.000 kg |
| Drive | Hybrid or diesel | Hybrid or diesel |
| Output | Hybrid: Power unit 110 kVa, Electric motor 75k W Diesel: diesel motor 104 kW/ 141 HP | Hybrid: Power unit 110 kVa, Electric motor 75k W Diesel: diesel motor 104 kW/ 141 HP |
| Cubic capacity | 4.5 L | 4.5 L |
| Fuel tank | 300 L | 300 L |
| Hopper volume | Up to 7.5 m³ | Up to 7.5 m³ |
| Dimensions Screen deck L x W | 6900 x 1250 mm | 6900 x 1250 mm |
| Fractions Screen deck | 10 - 200 mm | 10 - 200 mm |
| Star size | 300, 287, 230, 216 of 170 mm | 300, 287, 230, 216 of 170 mm |
| Star speed | 0 - 230 rpm | 0 - 230 rpm |
3:12
Parts
At Stoevelaar Machinery, you can not only find machines but also parts four our equipment. Thanks to our extensive range, technical expertise and years of experience, we are able to assist you as quickly as possible.-
Most parts are available from stock, ensuring you receive assistance as quickly as possible.
Service
Stoevelaar Machinery has its own in-house service team with extensive technical experience. This means we can support you with breakdowns and technical issues. Our service team operates throughout the Benelux and Germany and is available 24/7.-
In-house workshop where maintenance, repairs and modifications are carried out professionally.
Curious about our Neuenhauser 3--fraction starscreen?
We would be pleased to show you the capabilities of this machine.
